Processor

• 　Intel Socket P Core 2 Duo 45nm Processor, up to P8600 2.4Ghz FSB1066/800/667MHz

Chipset

• Intel GM45 + Intel ICH9M-E

Memory

• 2 x 204 Pin DDR3 SO-DIMM slot, up to 8GB 800/1066

External I/O Port

• 2 x DB9 RS-232
• 1 x DB15 VGA
• 1 x HDMI
• 2 x RJ45 GbE LAN
• 4 x USB 2.0
• 1 x Mic-in, Line-Out
• 1 x DC Power 3 Pin terminal block connector
• 1 x 2 Pin power switch connector
• 2 x LED indication
• 1 x COM 422/485 (COM3, default:RS-485)
• 1 x COM RS-232 (COM4)
• 1 x 10 Pin terminal block for 1 Ground/VCC/ 4 in & out DIDO

Storage

• 2 x 2.5" SATA HDD space
• 1 x external CF slot

Expansion Slot

• 1 x PCI/PCIe x 1 or 2 x PCI expansion

OS Support

• Windows XP Embedded, Windows Embedded Standard 7, Windows 7 Pro for Embedded

Power Input

• DC 9~32V, AC power input for option

CD/DVD-R Device

• Optional

Wireless

• 2 x antenna holes at front side for option

Optional Fan

• 2 x 40 x 40 mm System Fan space (rear and front)

Construction

• Steel and Aluminum Heat sink

Dimensions

• 　211.2 x 203.5 x 126
• 211.2 x 203.5 x 148 (with DVD device)

Mounting

• Wall Mount, optional Din Rail Mounting

Weight

• 2.5 kgs

Operating Temperature

• 0~50 °C

Storage Temperature

• -20~60 °C

Humidity

• 10~90%@ 40 °C, non-condensing

Certificate

• CE/FCC Class A
